What is Threaded Pipe Caps
Threaded pipe caps are fittings used to seal the ends of pipes. They have internal or external threads that match the threads on the pipe, enabling a secure connection by screwing onto the pipe.
Threaded pipe capsMade from materials like metal (carbon steel, stainless steel, etc.) and plastic, they are widely used in various piping systems for functions like preventing leakage, blocking dirt and debris, and facilitating maintenance.
Threaded pipe caps come in different shapes, sizes and thread types to suit different pipe specifications and application requirements.
Types of Threaded Pipe Caps
Standard Threaded Pipe Caps
Basic design with standard threads for common applications.
Heavy-Duty Threaded Pipe Caps
Reinforced for high-pressure and demanding environments.
Hexagonal Threaded Pipe Caps
Hexagonal shape for easy installation and removal.
Square Threaded Pipe Caps
Square shape, suitable for specific industrial applications.
Reducing Threaded Pipe Caps
Designed to fit pipes of different diameters.
Locking Threaded Pipe Caps
Feature locking mechanisms to prevent loosening.
Advantages of Threaded Pipe Caps
Easy installation and disassembly: no special tools are required, simple operation, suitable for quick installation.
Diverse materials and sizes: a variety of materials and sizes are available to adapt to different application scenarios.
Good sealing: the thread design ensures sealing and prevents leakage.
Pressure and temperature resistance: can withstand high pressure and extreme temperatures, and adapt to complex environments.
Compact design: small size, suitable for occasions with limited space.
Standards for Threaded Pipe Caps
ASME B16.11: Specifies forged pipe fittings sizes, pressure ratings, materials, and testing.
ASME B1.20.1: Defines NPT thread sizes for use in North American piping systems.
ASME B1.20.3: Specifies NPTF (tight) thread sizes.
MSS SP-83: Applies to threaded and welded fittings.
MSS SP-79, MSS SP-95: Specifies pipe cap sizes and properties.
DIN 2617, DIN 28011: German standards specifying pipe cap sizes and materials.
EN 10253: European standard for general purpose steel pipe fittings.
BS 3799: British standard specifying pipe cap specifications.
Material of Threaded Pipe Caps
Carbon Steel Threaded pipe caps
Grades: ASTM A105, ASTM A234, etc.
Applications: Widely used in oil and gas pipelines, chemical processing, and power generation due to its strength and durability.
Stainless Steel Threaded pipe caps
Grades: 304, 304L, 316, 316L.
Applications: Suitable for applications requiring corrosion resistance, such as food processing, pharmaceuticals, and marine environments.
Alloy Steel Threaded pipe caps
Grades: Various alloy steels with added elements for specific properties.
Applications: Used in high-pressure and high-temperature applications, such as power plants and chemical processing.
Applications of Threaded Pipe Caps
Plumbing: Seal water pipes, prevent debris, and aid maintenance.
Gas Distribution: Close unused branches, ensure no gas leaks.
Chemical & Petrochemical: Seal chemical pipes, prevent spills.
Manufacturing: Used in hydraulic/pneumatic systems, avoid leakage.
Electrical Conduit: Seal conduits, protect wires from damage.
Automotive & Aerospace: Prevent fluid/air leaks in vehicle systems.
