Stainless Steel Pipe Fitting

Stainless steel pipe fittings are components used to connect, control, redirect, or adapt the flow of fluids (liquids, gases, or slurries) in piping systems. They are made from stainless steel, a corrosion-resistant alloy that contains iron, chromium (typically 10.5% or more), and often other elements like nickel, molybdenum, or manganese. Stainless steel pipe fittings are widely used in industries where durability, hygiene, and resistance to corrosion and high temperatures are essential.

1. Elbow Fittings: Used to change the direction of flow, available in 45°, 90°, and 180° angles.

2. Tee Fittings: Allow for a branch connection, forming a T-shape.

3. Reducer Fittings: Connect pipes of different diameters, maintaining smooth flow.

4. Coupling Fittings: Connect two sections of a pipe, ensuring a secure and leak-free joint.

5. Cross Fittings: Unite four pipes together, forming a cross shape.

6. Union Fittings: Facilitate easy connection and disconnection of pipe sections for maintenance.

7. Cap Fittings: Close the end of a pipe to prevent fluid or gas flow.

8. Flange Fittings: Provide detachable joints, essential for maintenance and assembly

304 Stainless Steel:

Most commonly used grade.

Excellent corrosion resistance and versatility.

Suitable for general-purpose applications.

316/316L Stainless Steel:

Contains molybdenum for enhanced corrosion resistance, especially against chlorides and acids.

Ideal for marine, chemical, and high-temperature environments.

321 Stainless Steel:

Contains titanium for improved resistance to high temperatures and intergranular corrosion.

Used in high-temperature applications like exhaust systems.

Duplex Stainless Steel:

Combines high strength and excellent corrosion resistance.

Used in demanding environments like oil and gas.

1.Threaded Fittings:

Screwed onto pipes using threads.

Suitable for low-pressure applications.

2. Socket Weld Fittings:

Pipes are inserted into the fitting and welded for a strong, leak-proof connection.

Used in high-pressure systems.

3. Butt Weld Fittings:

Pipes and fittings are welded together end-to-end.

Ideal for high-pressure and high-temperature applications.

4. Flanged Fittings:

Connected using bolts and gaskets.

Used in systems requiring frequent disassembly.

1. Oil and Gas Industry:

Used in pipelines, refineries, and offshore platforms due to their corrosion resistance and strength.

2. Chemical and Petrochemical Industry:

Ideal for handling corrosive chemicals and high temperatures.

3. Food and Beverage Industry:

Preferred for their hygienic properties and ease of cleaning.

4. Pharmaceutical Industry:

Used in sterile and high-purity systems.

5. Water Treatment and Desalination:

Resistant to corrosion from water and chemicals.

6. Power Generation:

Used in high-temperature and high-pressure systems like boilers and turbines.

7. Marine and Shipbuilding:

Resistant to saltwater corrosion.
